psigma1-EGFP
(Plasmid #53611)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 53611 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pEGFP-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 5206
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    sigma 1
  • Alt name
    adaptor protein complex AP-1, sigma 1
  • Alt name
    AP-1, sigma1
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    473
  • Entrez Gene
    Ap1s1 (a.k.a. AP19)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer EGFP-N
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    psigma1-EGFP was a gift from Tom Kirchhausen (Addgene plasmid # 53611 ; http://n2t.net/addgene:53611 ; RRID:Addgene_53611)
  • For your References section:

    Dynamics of intracellular clathrin/AP1- and clathrin/AP3-containing carriers. Kural C, Tacheva-Grigorova SK, Boulant S, Cocucci E, Baust T, Duarte D, Kirchhausen T. Cell Rep. 2012 Nov 29;2(5):1111-9. doi: 10.1016/j.celrep.2012.09.025. Epub 2012 Oct 25. 10.1016/j.celrep.2012.09.025 PubMed 23103167
