pBW213ara-hrpS
(Plasmid #61435)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 61435 Plasmid sent as bacteria in agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBAD18-Cm
  • Backbone size w/o insert (bp) 6026
  • Total vector size (bp) 7094
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    rbs33-hrpS-ter
  • Species
    Synthetic
  • Insert Size (bp)
    1087
  • Promoter pBAD

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (destroyed during cloning)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer ATGCCATAGCATTTTTATCC
  • 3′ sequencing primer GATTTAATCTGTATCAGG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    This plasmid was created by ​Dr Baojun Wang
  • Terms and Licenses
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBW213ara-hrpS was a gift from Martin Buck & Baojun Wang (Addgene plasmid # 61435)
  • For your References section:

    Engineering modular and orthogonal genetic logic gates for robust digital-like synthetic biology. Wang B, Kitney RI, Joly N, Buck M. Nat Commun. 2011 Oct 18;2:508. doi: 10.1038/ncomms1516. 10.1038/ncomms1516 PubMed 22009040
