(Plasmid #65247)


Item Catalog # Description Quantity Price (USD)
Plasmid 65247 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 5446
  • Total vector size (bp) 6796
  • Modifications to backbone
    in-frame HA tag between ApaI and XhoI sites of pcDNA3
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Mutation
    changed Ser311 to Asp, Ser315 to Asp
  • GenBank ID
  • Entrez Gene
    MAP2K5 (a.k.a. HsT17454, MAPKK5, MEK5, PRKMK5)
  • Promoter CMV
  • Tag / Fusion Protein
    • HA (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer CACTGCTTACTGGCTTATCG
  • 3′ sequencing primer TGGCAACTAGAAGGCACAG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3-MEK5DD-HA was a gift from Axel Ullrich (Addgene plasmid # 65247 ; ; RRID:Addgene_65247)
  • For your References section:

    Phosphotyrosine-specific phosphatase PTP-SL regulates the ERK5 signaling pathway. Buschbeck M, Eickhoff J, Sommer MN, Ullrich A. J Biol Chem. 2002 Aug 16;277(33):29503-9. Epub 2002 May 31. 10.1074/jbc.M202149200 PubMed 12042304
