3xgRNA: PTEN exon 5, p53 exon 8, SMAD4 exon 2 probasin_mTQ2_FlpO
(Plasmid #68405)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 68405 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 68405-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 68405-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    Amp
  • Backbone size w/o insert (bp) 2500
  • Total vector size (bp) 7648
  • Vector type
    Mammalian Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    3xgRNA: PTEN exon 5, p53 exon 8, SMAD4 exon 2
  • Alt name
    gRNAs target PTEN exon 5, p53 exon 8, SMAD4 exon 2
  • Species
    Synthetic
  • Insert Size (bp)
    1059
  • Promoter U6

Cloning Information for Gene/Insert 1

  • Cloning method Restriction Enzyme
  • 5′ cloning site NruI (unknown if destroyed)
  • 3′ cloning site KpnI (unknown if destroyed)
  • 5′ sequencing primer ttttggcaagtcagttaggaca
  • 3′ sequencing primer GGAATGGTAGATGTTTAAAC
  • (Common Sequencing Primers)

Gene/Insert 2

  • Gene/Insert name
    FlpO
  • Species
    Synthetic
  • Insert Size (bp)
    1300
  • Promoter Synthetic Probasin ARRx2
  • Tag / Fusion Protein
    • mTurquoise2 (BFP) (N terminal on insert)

Cloning Information for Gene/Insert 2

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (unknown if destroyed)
  • 3′ cloning site PacI (unknown if destroyed)
  • 5′ sequencing primer GGAATGGTAGATGTTTAAAC
  • 3′ sequencing primer aagtcgtgctgcttcatgtg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    3xgRNA: PTEN exon 5, p53 exon 8, SMAD4 exon 2 probasin_mTQ2_FlpO was a gift from Jannik Elverløv-Jakobsen (Addgene plasmid # 68405 ; http://n2t.net/addgene:68405 ; RRID:Addgene_68405)
