(Plasmid #70757)


Item Catalog # Description Quantity Price (USD)
Plasmid 70757 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 5367
  • Total vector size (bp) 6259
  • Modifications to backbone
    modified MCS including C-terminal thrombin cleavage site and 6xHIS tag
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    Low Copy


  • Gene/Insert name
  • Alt name
  • Alt name
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    APEX1 (a.k.a. APE, APE1, APEN, APEX, APX, HAP1, REF1)
  • Promoter T7/lac operon
  • Tag / Fusion Protein
    • 6-HIS (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NcoI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer pBRrevBam
  • 3′ sequencing primer T7 terminal
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET28HIS-hAPE1 was a gift from Primo Schaer (Addgene plasmid # 70757 ; ; RRID:Addgene_70757)
  • For your References section:

    3CAPS - a structural AP-site analogue as a tool to investigate DNA base excision repair. Schuermann D, Scheidegger SP, Weber AR, Bjoras M, Leumann CJ, Schar P. Nucleic Acids Res. 2016 Jan 4. pii: gkv1520. 10.1093/nar/gkv1520 PubMed 26733580
