(Plasmid #78860)


Item Catalog # Description Quantity Price (USD)
Plasmid 78860 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 5428
  • Modifications to backbone
    Firefly luciferase, BCL2L1 inserted via LR reaction
  • Vector type
    Mammalian Expression ; Expression vector
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
    BCL2 like 1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    BCL2L1 (a.k.a. BCL-XL/S, BCL2L, BCLX, Bcl-X, PPP1R52)
  • Promoter CMV
  • Tag / Fusion Protein
    • Firefly luciferase, V5-tag (N terminal on insert)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer CMVF_pcDNA3, T7F
  • 3′ sequencing primer bGH reverse
  • (Common Sequencing Primers)

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FL-BCL2L1 was a gift from Erich Wanker (Addgene plasmid # 78860 ; ; RRID:Addgene_78860)
  • For your References section:

    DULIP: A Dual Luminescence-Based Co-Immunoprecipitation Assay for Interactome Mapping in Mammalian Cells. Trepte P, Buntru A, Klockmeier K, Willmore L, Arumughan A, Secker C, Zenkner M, Brusendorf L, Rau K, Redel A, Wanker EE. J Mol Biol. 2015 Oct 23;427(21):3375-88. doi: 10.1016/j.jmb.2015.08.003. Epub 2015 Aug 8. 10.1016/j.jmb.2015.08.003 PubMed 26264872
