Addgene

Venus wGBD
(Plasmid #85222)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 85222 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5428
  • Total vector size (bp) 6426
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    wGBD
  • Alt name
    N-WASP
  • Alt name
    Neuronal Wiskott-Aldrich Syndrome protein
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    276
  • Mutation
    Cdc42 binding domain of N-WASP
  • Entrez Gene
    WASL (a.k.a. N-WASP, NWASP, WASPB)
  • Promoter CMV
  • Tag / Fusion Protein
    • Venus (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site EcoR1 (not destroyed)
  • 5′ sequencing primer T7 primer
  • 3′ sequencing primer BGH reverse primer
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

There is a KpnI site between Venus and wGBD

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Venus wGBD was a gift from Narasimhan Gautam (Addgene plasmid # 85222 ; http://n2t.net/addgene:85222 ; RRID:Addgene_85222)
  • For your References section:

    Subcellular optogenetic activation of Cdc42 controls local and distal signaling to drive immune cell migration. O'Neill PR, Kalyanaraman V, Gautam N. Mol Biol Cell. 2016 May 1;27(9):1442-50. doi: 10.1091/mbc.E15-12-0832. Epub 2016 Mar 3. 10.1091/mbc.E15-12-0832 PubMed 26941336
