pJB066
(Plasmid #98913)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 98913 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pDR175
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    FtsZ
  • Species
    E. coli
  • Insert Size (bp)
    1149
  • GenBank ID
    NC_000913.3
  • Promoter pBAD
  • Tag / Fusion Protein
    • pAmCherry1 (C terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CTTTAAGAAGGAGATATACG
  • 3′ sequencing primer CTTTACTAAGCTTGCATGCCTG
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJB066 was a gift from Jie Xiao (Addgene plasmid # 98913 ; http://n2t.net/addgene:98913 ; RRID:Addgene_98913)
  • For your References section:

    A multi-layered protein network stabilizes the Escherichia coli FtsZ-ring and modulates constriction dynamics. Buss J, Coltharp C, Shtengel G, Yang X, Hess H, Xiao J. PLoS Genet. 2015 Apr 7;11(4):e1005128. doi: 10.1371/journal.pgen.1005128. eCollection 2015 Apr. PGENETICS-D-14-03238 [pii] PubMed 25848771
