pcDNA3.1 HA-YY1
(Plasmid #104395)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 104395 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 5800
  • Total vector size (bp) 6700
  • Modifications to backbone
    Added HA tag
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    YY1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1200
  • GenBank ID
    NM_003403
  • Entrez Gene
    YY1 (a.k.a. DELTA, GADEVS, INO80S, NF-E1, UCRBP, YIN-YANG-1)
  • Promoter CMV
  • Tag / Fusion Protein
    • HA (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site EcoRV (not destroyed)
  • 5′ sequencing primer T7_prom
  • 3′ sequencing primer BGH_rev
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Yang Shi
  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1 HA-YY1 was a gift from Richard Young (Addgene plasmid # 104395 ; http://n2t.net/addgene:104395 ; RRID:Addgene_104395)
  • For your References section:

    YY1 Is a Structural Regulator of Enhancer-Promoter Loops. Weintraub AS, Li CH, Zamudio AV, Sigova AA, Hannett NM, Day DS, Abraham BJ, Cohen MA, Nabet B, Buckley DL, Guo YE, Hnisz D, Jaenisch R, Bradner JE, Gray NS, Young RA. Cell. 2017 Dec 14;171(7):1573-1588.e28. doi: 10.1016/j.cell.2017.11.008. Epub 2017 Dec 7. 10.1016/j.cell.2017.11.008 PubMed 29224777
