(Plasmid #12613)


Item Catalog # Description Quantity Price (USD)
Plasmid 12613 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    dorsal RHR in pB1H2
  • Alt name
  • Species
    D. melanogaster (fly)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    dl (a.k.a. Dmel_CG6667, CG6667, DL, Dl, Dmel\CG6667, Dor, Dorsal, GSd447, NFkappaB, anon-EST:GressD7, d, dL, fs(2)k10816, mat(2)dorsal, p65)
  • Tag / Fusion Protein
    • flag (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site AvrII (not destroyed)
  • 5′ sequencing primer CGTGATGTACGTCAGCCTGAAG
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pB1H2 was a gift from Scot Wolfe (Addgene plasmid # 12613 ; ; RRID:Addgene_12613)
  • For your References section:

    A bacterial one-hybrid system for determining the DNA-binding specificity of transcription factors. Meng X, Brodsky MH, Wolfe SA. Nat Biotechnol. 2005 Aug . 23(8):988-94. 10.1038/nbt1120 PubMed 16041365
