CaYin1 NES
(Plasmid #33318)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 33318 Plasmid sent as bacteria in agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pcDNA3
  • Backbone manufacturer
    invitrogen
  • Backbone size w/o insert (bp) 5500
  • Modifications to backbone
    multiple cloning sites have been modified and it has the same reading frame as in pBAD hisB vector
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CaYin1 NES
  • Alt name
    tdtomato mAmetrine1.2 FRET calcium sensor
  • Species
    synthetic construct
  • Insert Size (bp)
    2652
  • GenBank ID
    JQ031556
  • Promoter CMV
  • Tag / Fusion Protein
    • NES sequence LALKLAGLDIGS (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho1 (not destroyed)
  • 3′ cloning site EcoR1 (not destroyed)
  • 5′ sequencing primer T7_fwr_primer
  • 3′ sequencing primer BGH_rev_primer
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CaYin1 NES was a gift from Robert Campbell (Addgene plasmid # 33318)
  • For your References section:

    Forster resonance energy transfer-based biosensors for multiparameter ratiometric imaging of Ca2+ dynamics and caspase-3 activity in single cells. Ding Y, Ai HW, Hoi H, Campbell RE. Anal Chem. 2011 Dec 15;83(24):9687-93. doi: 10.1021/ac202595g. Epub 2011 Nov 28. 10.1021/ac202595g PubMed 22080726
