pAAV-hysn-flex-dsRed-shscramble
(Plasmid #71383)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 71383 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pUC
  • Backbone size w/o insert (bp) 3000
  • Total vector size (bp) 6035
  • Vector type
    Mammalian Expression, AAV, RNAi, Cre/Lox

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    human synapsin promoter-flex switch-dsRed-shscramble
  • Species
    H. sapiens (human), M. musculus (mouse), Synthetic
  • Insert Size (bp)
    3000
  • Promoter human synapsin

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoR1 (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer CGTAATGCAGAAGAAGACTATG
  • 3′ sequencing primer CCATGTAGATGGACTTGAACTC
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    this plasmid is modified from the pRIME system. See: Stegmeier, F., Hu, G., Rickles, R.J., Hannon, G.J., and Elledge, S.J. (2005). A lentiviral microRNA-based system for single-copy polymerase II-regulated RNA interference in mammalian cells. Proc. Natl. Acad. Sci. USA 102, 13212–13217 We used The pPRIME-CMV-dsRed-FF3 vector, a gift from Stephen Elledge (Addgene plasmid 11664), as the building block to make the AAV-hsyn-flex-dsRed-shscramble plasmid

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

this plasmid is modified from the pRIME system. See:
Stegmeier, F., Hu, G., Rickles, R.J., Hannon, G.J., and Elledge, S.J. (2005). A
lentiviral microRNA-based system for single-copy polymerase II-regulated
RNA interference in mammalian cells. Proc. Natl. Acad. Sci. USA 102,
13212–13217
We used The pPRIME-CMV-dsRed-FF3 vector, a gift from Stephen Elledge (Addgene plasmid 11664), as the building block to make the AAV-hsyn-flex-dsRed-shscramble plasmid

All the enzymes are unique cutters, except EcoRI and XhoI, the insert dsRed-shRNA can be retrieved using AscI and NheI, giving 1.2kb and 4.8kb bands.

The insert was read using primers in the dsred sequence:
dsred 410: CGTAATGCAGAAGAAGACTATG
dsred 530R: CCATGTAGATGGACTTGAACTC

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-hysn-flex-dsRed-shscramble was a gift from William Wisden (Addgene plasmid # 71383 ; http://n2t.net/addgene:71383 ; RRID:Addgene_71383)
  • For your References section:

    Wakefulness Is Governed by GABA and Histamine Cotransmission. Yu X, Ye Z, Houston CM, Zecharia AY, Ma Y, Zhang Z, Uygun DS, Parker S, Vyssotski AL, Yustos R, Franks NP, Brickley SG, Wisden W. Neuron. 2015 Jun 17. pii: S0896-6273(15)00516-4. doi: 10.1016/j.neuron.2015.06.003. 10.1016/j.neuron.2015.06.003 PubMed 26094607
