(Plasmid #102367)


Item Catalog # Description Quantity Price (USD)
Plasmid 102367 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 3882
  • Total vector size (bp) 4629
  • Modifications to backbone
    human synapsin I promoter
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    E. coli, herpes simplex virus
  • Insert Size (bp)
  • Mutation
    rtTA variant reported in Gene Therapy (2006) 13, 1382–1390
  • Promoter human synapsin I promoter

Cloning Information

  • Cloning method Unknown
  • 5′ sequencing primer GGGTATGATGCCTGTCCAGC
  • 3′ sequencing primer TTATTAGGACAAGGCTGGTG
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Human synapsin I promoter was cloned by Dr. Hiroyuki Hioki.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This vector was also used in two-photon calcium imaging paper. Sadakane et al. Cell Rep. (2015) 13(9):1989-99. PMID: 26655910. The TV16 mutation was introduced to pTET-ON advanced by Drs. Ryosuke Matsui and Dai Watanabe of Kyoto university. The details of the mutation was originally reported in Gene Therapy (2006) 13, 1382–1390. The human synapsin I promoter was cloned by Dr. Hiroyuki Hioki in Kyoto university.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    AAV-hSynI-rtTAV16 was a gift from Tetsuo Yamamori (Addgene plasmid # 102367 ; ; RRID:Addgene_102367)
  • For your References section:

    Simultaneous visualization of extrinsic and intrinsic axon collaterals in Golgi-like detail for mouse corticothalamic and corticocortical cells: a double viral infection method. Watakabe A, Takaji M, Kato S, Kobayashi K, Mizukami H, Ozawa K, Ohsawa S, Matsui R, Watanabe D, Yamamori T. Front Neural Circuits. 2014 Sep 17;8:110. doi: 10.3389/fncir.2014.00110. eCollection 2014. 10.3389/fncir.2014.00110 PubMed 25278843
