PLL7.0 tgRFP LOV
(Plasmid
#114463)
-
PurposeMammalian expression of tgRFP labelled LOV2
-
Depositing Lab
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 114463 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
This material is available to academics and nonprofits only.
Backbone
-
Vector backbonePLL 7.0
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameLOV2
-
Insert Size (bp)480
-
MutationG401A(G528A), N411E(N538E) and V289I (V416I)
- Promoter CMV
-
Tag
/ Fusion Protein
- tgRFP (N terminal on insert)
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer GAGCTGTACAAGtcc (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Plasmid lacks features necessary for lentiviral production, but should be unaffected for mammalian expression of tgRFP LOV.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
PLL7.0 tgRFP LOV was a gift from Andrew Woolley (Addgene plasmid # 114463 ; http://n2t.net/addgene:114463 ; RRID:Addgene_114463) -
For your References section:
Discovering Selective Binders for Photoswitchable Proteins Using Phage Display. Reis JM, Xu X, McDonald S, Woloschuk RM, Jaikaran ASI, Vizeacoumar FS, Woolley GA, Uppalapati M. ACS Synth Biol. 2018 Oct 19;7(10):2355-2364. doi: 10.1021/acssynbio.8b00123. Epub 2018 Sep 27. 10.1021/acssynbio.8b00123 PubMed 30203962
