(Plasmid #115639)


Item Catalog # Description Quantity Price (USD)
Plasmid 115639 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Vector type
    Mammalian Expression
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    Can be grown at 37°C in TOP10 E. coli.
  • Copy number
    High Copy


  • Gene/Insert name
  • Species
    H. sapiens (human)
  • Entrez Gene
    NODAL (a.k.a. HTX5)
  • Promoter TRE3G

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site MluI (not destroyed)
  • 5′ sequencing primer TRE3G (GATCGCCTGGAGCAATTCCAC)
  • 3′ sequencing primer SV40pA-R
  • (Common Sequencing Primers)

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Use with TALENs #52341 and #52342. Please visit for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    AAVS1-TRE3G-NODAL-matMYC was a gift from Lynne Postovit (Addgene plasmid # 115639 ; ; RRID:Addgene_115639)
  • For your References section:

    Genetically regulated human NODAL splice variants are differentially post-transcriptionally processed and functionally distinct. Findlay SD, Bilyk O, Lypka K, Waskiewicz AJ, Postovit L. (2018) bioRxiv 276170 10.1101/276170
