PurposeAAV-mediated expression of Archon1-KGC-GFP-ER2 under the Syn promoter. Using bGHpA signal.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||115892||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
|AAV8||115892-AAV8||Virus (100 µL at titer ≥ 7×10¹² vg/mL) and Plasmid.||$380|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 4451
- Total vector size (bp) 6056
Vector typeMammalian Expression, AAV
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Growth Strain(s)NEB Stable
Growth instructionsCan use DH5alpha at 37°C or Stbl3 at 30°C. Carbenicillin is preferred over ampicillin. In DH5alpha this plasmid may act more like a high copy plasmid, although in Stbl3 it may act more like a low copy plasmid.
Copy numberLow Copy
Insert Size (bp)1605
- Promoter Syn
/ Fusion Proteins
- KGC (C terminal on insert)
- GFP (C terminal on insert)
- ER2 (C terminal on insert)
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer GCG AGG CGC GAG ATA G
- 3′ sequencing primer CAA GGA GGA GAA AAT GAA AGC C (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
The plasmid is fully sequenced in the coding sequence regions (opsin-fluorophore and important flanking regions). Multiple digestions were done to verify the vector structure. The construct was tested in vitro.
Information for AAV8 (Catalog # 115892-AAV8) ( Back to top )
Ready-to-use AAV8 particles produced from pAAV-Syn-Archon1-KGC-GFP-ER2 (#115892). In addition to the viral particles, you will also receive purified pAAV-Syn-Archon1-KGC-GFP-ER2 plasmid DNA.Syn-driven Archon1, an opsin-based fluorescent voltage indicator, fused to EGFP. These AAV preparations are suitable purity for injection into animals.
- Volume 100 µL
- Titer ≥ 7×10¹² vg/mL
- Pricing $350 USD for preparation of 100 µL virus + $30 USD for plasmid.
- Storage Store at -80℃. Thaw just before use and keep on ice.
- Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.
Viral Production & Use
- Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, AAV8 cap gene
- Buffer PBS + 0.001% Pluronic F-68
- Serotype AAV8
- Purification Iodixanol gradient ultracentrifugation
- Reporter Gene GFP
Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide
Viral Quality Control
- Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
- Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.
Visit our viral production page for more information.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pAAV-Syn-Archon1-KGC-GFP-ER2 was a gift from Edward Boyden (Addgene plasmid # 115892 ; http://n2t.net/addgene:115892 ; RRID:Addgene_115892)
For viral preps, please replace (Addgene plasmid # 115892) in the above sentence with: (Addgene viral prep # 115892-AAV8)
For your References section:A robotic multidimensional directed evolution approach applied to fluorescent voltage reporters. Piatkevich KD, Jung EE, Straub C, Linghu C, Park D, Suk HJ, Hochbaum DR, Goodwin D, Pnevmatikakis E, Pak N, Kawashima T, Yang CT, Rhoades JL, Shemesh O, Asano S, Yoon YG, Freifeld L, Saulnier JL, Riegler C, Engert F, Hughes T, Drobizhev M, Szabo B, Ahrens MB, Flavell SW, Sabatini BL, Boyden ES. Nat Chem Biol. 2018 Feb 26. pii: 10.1038/s41589-018-0004-9. doi: 10.1038/s41589-018-0004-9. 10.1038/s41589-018-0004-9 PubMed 29483642
