|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||117771||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
Backbone manufacturerKarl J. Clark
- Backbone size w/o insert (bp) 2856
Vector typeSynthetic Biology
Growth in Bacteria
Growth Strain(s)NEB Stable
Copy numberHigh Copy
Gene/Insert name3x3 Stop sequence
SpeciesD. rerio (zebrafish)
Insert Size (bp)3387
- Cloning method Gibson Cloning
- 5′ sequencing primer aaaagcaagaaagaaaactagagtgg
- 3′ sequencing primer atggctcataacaccccttg (Common Sequencing Primers)
Terms and Licenses
Secondary gene is a gamma-crystalin promoter driving NLS-TagBFP. Online tools and cloning help available at <www.genesculpt.org/gtaghd/>. May work in additional species beyond those listed. Please note that some discrepancies were found between Addgene's quality control result and the depositor's provided sequence. The depositor noted that these discrepancies do NOT affect plasmid function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pPRISM-Stop-gcry-TagBFP was a gift from Jeffrey Essner (Addgene plasmid # 117771 ; http://n2t.net/addgene:117771 ; RRID:Addgene_117771)
For your References section:GeneWeld: a method for efficient targeted integration directed by short homology. Wierson WA, Welker JM, Almeida MP, Mann CM, Webster DA, Weiss TJ, Torrie ME, Vollbrecht MK, Lan M, McKeighan KC, Ming Z, Wehmeier A, Mikelson CS, Haltom JA, Kwan KM, Chien CB, Balciunas D, Ekker SC, Clark KJ, Webber BR, Moriarity B, Solin SL, Carlson DF, Dobbs DL, McGrail M, Essner JJ.. bioRxiv 431627 10.1101/431627
