mCherry-TMCC1
(Plasmid #120932)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 120932 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pAcGFP1-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 6657
  • Modifications to backbone
    mCh tag was amplified and inserted into the NheI and XhoI sites in order to replace the GFP.
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Trans membrane and coiled coil domain containing protein 1
  • Alt name
    TMCC1
  • Alt name
    KIAA0779
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1962
  • GenBank ID
    NM_001349265.1
  • Entrez Gene
    TMCC1
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho1 (not destroyed)
  • 3′ cloning site Kpn1 (not destroyed)
  • 5′ sequencing primer ATG GAG CCT TCG GGC AGT GAA CAG
  • 3′ sequencing primer TCT AGG GGA TGA AAA GAA CCG TTC CAC ATA GC
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    mCherry-TMCC1 was a gift from Gia Voeltz (Addgene plasmid # 120932 ; http://n2t.net/addgene:120932 ; RRID:Addgene_120932)
  • For your References section:

    A Novel Class of ER Membrane Proteins Regulates ER-Associated Endosome Fission. Hoyer MJ, Chitwood PJ, Ebmeier CC, Striepen JF, Qi RZ, Old WM, Voeltz GK. Cell. 2018 Sep 20;175(1):254-265.e14. doi: 10.1016/j.cell.2018.08.030. Epub 2018 Sep 13. 10.1016/j.cell.2018.08.030 PubMed 30220460
