pcDNA3-PBD-EYFP
(Plasmid #13723)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 13723 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pcDNA3
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5500
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PBD-EYFP
  • Alt name
    PBD
  • Alt name
    Pak1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1000
  • Mutation
    p21 binding domain of human Pak1(amino acids 65-150)
  • Entrez Gene
    PAK1 (a.k.a. IDDMSSD, PAKalpha, alpha-PAK, p65-PAK)
  • Tag / Fusion Protein
    • EYFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer T7
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Protocols for production and use of Hahn lab biosensors and photactivatable proteins
can be found on their web page, at the URL below. If you have
suggestions for the protocols or have any questions, please feel free to contact the Hahn
lab. Good luck with your experiments!

Hahn lab biosensor protocol: http://www.hahnlab.com/tools/index.html

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3-PBD-EYFP was a gift from Klaus Hahn (Addgene plasmid # 13723 ; http://n2t.net/addgene:13723 ; RRID:Addgene_13723)
  • For your References section:

    Localized Rac activation dynamics visualized in living cells. Kraynov VS, Chamberlain C, Bokoch GM, Schwartz MA, Slabaugh S, Hahn KM. Science. 2000 Oct 13. 290(5490):333-7. 10.1126/science.290.5490.333 PubMed 11030651
