pSH1/Sn-E-Fv'Fvls-E
(Plasmid #15274)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 15274 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pSH1
  • Backbone manufacturer
    GR Crabtree lab
  • Backbone size w/o insert (bp) 3500
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    FKBP12(V36)
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    750
  • Mutation
    FKBP12 F36V
  • Entrez Gene
    FKBP1A (a.k.a. FKBP-12, FKBP-1A, FKBP1, FKBP12, PKC12, PKCI2, PPIASE)
  • Tags / Fusion Proteins
    • HA epitope (C terminal on insert)
    • HA epitope (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NotI, SacII (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer gaggtgttacttctgctctaaaagc
  • 3′ sequencing primer cactgcattctagttgtggtttg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSH1/Sn-E-Fv'Fvls-E was a gift from David Spencer (Addgene plasmid # 15274 ; http://n2t.net/addgene:15274 ; RRID:Addgene_15274)
  • For your References section:

    Improved artificial death switches based on caspases and FADD. Fan L, Freeman KW, Khan T, Pham E, Spencer DM. Hum Gene Ther. 1999 Sep 20. 10(14):2273-85. 10.1089/10430349950016924 PubMed 10515447
