R620-M06-303: CMV51p> TPAss-SARS-CoV-2 S-RBD(319-529)-3C-His8-SBP K417N/E484K/N501Y
(Plasmid #170192)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 170192 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 170192-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 170192-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pDest-303
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    SARS-CoV-2 RBD
  • Species
    SARS-CoV-2
  • Mutation
    K417N, E484K, N501Y
  • Entrez Gene
    S (a.k.a. GU280_gp02, spike glycoprotein)
  • Promoter CMV51
  • Tag / Fusion Protein
    • 3C-His8-SBP (C terminal on insert)

Cloning Information

  • Cloning method Gateway Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

DNA sequence optimized for mammalian expression

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    R620-M06-303: CMV51p> TPAss-SARS-CoV-2 S-RBD(319-529)-3C-His8-SBP K417N/E484K/N501Y was a gift from Dominic Esposito (Addgene plasmid # 170192 ; http://n2t.net/addgene:170192 ; RRID:Addgene_170192)

  • For your References section:

    Improved production of SARS-CoV-2 spike receptor-binding domain (RBD) for serology assays. Mehalko J, Drew M, Snead K, Denson JP, Wall V, Taylor T, Sadtler K, Messing S, Gillette W, Esposito D. Protein Expr Purif. 2021 Mar;179:105802. doi: 10.1016/j.pep.2020.105802. Epub 2020 Nov 25. 10.1016/j.pep.2020.105802 PubMed 33248226
