Epac-S-H189
(Plasmid #170350)

• Purpose: mT2Del_EPACdDEPCD_Q270E_tdBlackcp173Ven(ST) biosensor to measure realtime changes in FRET reflecting fluctuations in cAMP levels in living cells.
• Depositing Lab: Kees Jalink
• Publication: Klarenbeek et al PLoS One. 2015 Apr 14;10(4):e0122513. doi: 10.1371/journal.pone.0122513. eCollection 2015.

Backbone

• Vector backbone: pcDNA3
• Backbone size w/o insert (bp): 5500
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: mT2Del_EPACdDEPCD_Q270E_tdBlackcp173Ven(ST)
• Species: H. sapiens (human)
• Mutation: Deletion of DEP domain, Catalytically dead T781A & F782A, increased affinity for cAMP Q270E
• Entrez Gene: RAPGEF3 (a.k.a. CAMP-GEFI, EPAC, EPAC1, HSU79275, bcm910)
• Promoter: CMV

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: Unknown (unknown if destroyed)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
