SIN40C.SFFV.dCas9-KRAB.P2A.mNeon
(Plasmid
#170482)
-
PurposeLentiviral dSpCas9-KRAB (CRISPRi) delivery, mNeon coexpression
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 170482 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $89 |
Backbone
-
Vector backboneSIN40C
- Total vector size (bp) 12435
-
Modifications to backbonemodified pLKO.005
-
Vector typeLentiviral
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert 1
-
Gene/Insert namedCas9-KRAB
-
SpeciesSynthetic; S. pyogenes
-
Insert Size (bp)4482
-
Tag
/ Fusion Protein
- HA (N terminal on insert)
Gene/Insert 2
-
Gene/Insert nameSFFV
-
Alt nameSpleen Focus Forming Virus Promoter Enhancer
-
SpeciesH. sapiens (human)
-
Insert Size (bp)413
Gene/Insert 3
-
Gene/Insert nameP2A-mNeonGreen
-
SpeciesSynthetic
-
Insert Size (bp)780
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
SIN40C.SFFV.dCas9-KRAB.P2A.mNeon was a gift from Dirk Heckl (Addgene plasmid # 170482 ; http://n2t.net/addgene:170482 ; RRID:Addgene_170482) -
For your References section:
Myeloid leukemia vulnerabilities embedded in long noncoding RNA locus MYNRL15. Ng M, Verboon L, Issa H, Bhayadia R, Vermunt MW, Winkler R, Schuler L, Alejo O, Schuschel K, Regenyi E, Borchert D, Heuser M, Reinhardt D, Yaspo ML, Heckl D, Klusmann JH. iScience. 2023 Sep 7;26(10):107844. doi: 10.1016/j.isci.2023.107844. eCollection 2023 Oct 20. 10.1016/j.isci.2023.107844 PubMed 37766974
