(Plasmid #173072)


Item Catalog # Description Quantity Price (USD)
Plasmid 173072 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 4091
  • Total vector size (bp) 6686
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
  • Alt name
    pericentrin AKAP450 centrosomal-targeting domain
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Promoter CMV IE94
  • Tag / Fusion Protein
    • mCherry-SNAP-SNAP-Varied (N terminal on insert)

Cloning Information

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    John Scott Lab, University of Washington, Seattle WA

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The SNAP gene/insert was a gift from the Scott lab as part of collaboration on the manuscript entitled "Subcellular drug targeting illuminates local kinase action"

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCS2-mCherry_SNAP_SNAPV_PACT_Active was a gift from Heidi Hehnly (Addgene plasmid # 173072 ; ; RRID:Addgene_173072)
  • For your References section:

    Subcellular drug targeting illuminates local kinase action. Bucko PJ, Lombard CK, Rathbun L, Garcia I, Bhat A, Wordeman L, Smith FD, Maly DJ, Hehnly H, Scott JD. Elife. 2019 Dec 24;8. pii: 52220. doi: 10.7554/eLife.52220. 10.7554/eLife.52220 PubMed 31872801
