pYTRW20K_0Ti1
(Plasmid #177289)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 177289 Standard format: Plasmid sent in bacteria as agar stab 1 $89

Backbone

  • Vector backbone
    yTREX backbone
  • Backbone size w/o insert (bp) 9145
  • Vector type
    Bacterial Expression, Synthetic Biology ; Yeast Expression, rrn genomic integration
  • Selectable markers
    URA3 ; Tetracycline

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Ptet-tetA(C)
  • Alt name
    tetracycline resistance module - TcR
  • Alt name
    Tetracycline efflux pump
  • Species
    Synthetic
  • Insert Size (bp)
    1273

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CCTCAATACGTGCTGCAAC
  • 3′ sequencing primer GCCAAATTGCGTCAAGATCC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Part of the pYT vector series which enables chromosomal interposon integration via HR in synthetic rrn "landing pads" within 16S rRNA genes of equipped strains. The vector carries the "empty" YT_core with specific cloning slots separated by designated upstream and downstream sequences for integron customization, with TcR marker. Target genes can be inserted at the I-SceI site; additional promoter or reporter elements may be integrated at further positions. The vector backbone, based on the yTREX vector, is equipped with the bacterial pMB1 ori, aphII-encoded KmR and mob gene from pBBR1 (promoter and oriT region) and with yeast replication elements CEN4-ARS1 and URA3 marker. Note: vector pYTRW0268K_0Ti1 also has SacB for counter selection.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pYTRW20K_0Ti1 was a gift from Karl-Erich Jaeger (Addgene plasmid # 177289 ; http://n2t.net/addgene:177289 ; RRID:Addgene_177289)
  • For your References section:

    The modular pYT vector series employed for chromosomal gene integration and expression to produce carbazoles and glycolipids in P. putida. Weihmann R, Kubicki S, Bitzenhofer NL, Domrose A, Bator I, Kirschen LM, Kofler F, Funk A, Tiso T, Blank LM, Jaeger KE, Drepper T, Thies S, Loeschcke A. FEMS Microbes. 2022 Dec 19;4:xtac030. doi: 10.1093/femsmc/xtac030. eCollection 2023. 10.1093/femsmc/xtac030 PubMed 37333445
