(Plasmid #187899)


Item Catalog # Description Quantity Price (USD)
Plasmid 187899 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 5400
  • Total vector size (bp) 7800
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    Ikbkg (a.k.a. 1110037D23Rik, IKK[g], NEMO)
  • Promoter CMV
  • Tag / Fusion Protein
    • Halo (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (destroyed during cloning)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer 5'-GTCGAAGAATACATGGACTG
  • 3′ sequencing primer NA
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Subcloned from plasmid provided by E. Laplantine (Institut Pasteur); Tarantino et al., JCB 2014

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Halo-NEMO was a gift from Erika Holzbaur (Addgene plasmid # 187899 ; ; RRID:Addgene_187899)
  • For your References section:

    Damaged mitochondria recruit the effector NEMO to activate NF-kappaB signaling. Harding O, Holzer E, Riley JF, Martens S, Holzbaur ELF. Mol Cell. 2023 Sep 7;83(17):3188-3204.e7. doi: 10.1016/j.molcel.2023.08.005. 10.1016/j.molcel.2023.08.005 PubMed 37683611
