pUN1308 - pL2_pNOS-RLUC-tNOS_tOCS-FLUC-pNMT
(Plasmid
#203900)
-
PurposeReporter plasmid for the NMT promoter from C. roseus with firefly luciferase readout and Renilla luciferase normalization in a plant binary vector for Agrobacterium-mediated transformation.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 203900 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSB90
-
Backbone manufacturerMortensen et al., 2019 (doi:10.3389/fpls.2019.00755)
-
Vector typePlant Expression, Luciferase
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namepNMT-FLUC-tOCS; pNOS-RLUC-tNOS
-
SpeciesSynthetic; Catharanthus roseus var. LBE
-
Insert Size (bp)5283
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site unknown (destroyed during cloning)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pUN1308 - pL2_pNOS-RLUC-tNOS_tOCS-FLUC-pNMT was a gift from Carolyn Lee-Parsons (Addgene plasmid # 203900 ; http://n2t.net/addgene:203900 ; RRID:Addgene_203900) -
For your References section:
Identification of DELLA and GID1 genes in Catharanthus roseus and their potential role in regulating vindoline biosynthesis. Cole-Osborn LF, Soens N, Bernal-Franco D, Prifti O, Cram EJ, Lee-Parsons CWT. Plant Mol Biol. 2025 Jun 5;115(3):72. doi: 10.1007/s11103-025-01599-1. 10.1007/s11103-025-01599-1 PubMed 40471459
