pNES-EGFP-C1-flex-PABD-Spo20
(Plasmid #220081)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 220081 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pEGFP-C1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Spo20
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    123
  • Mutation
    amino acids 51-91
  • Entrez Gene
    SPO20 (a.k.a. YMR017W, DBI9)
  • Promoter CMV
  • Tag / Fusion Protein
    • X. leavis map2k1.L(32-44)-EGFP-SGGGSGGS (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNES-EGFP-C1-flex-PABD-Spo20 was a gift from Gerry Hammond (Addgene plasmid # 220081 ; http://n2t.net/addgene:220081 ; RRID:Addgene_220081)

  • For your References section:

    PILS-Nir1 is a sensitive phosphatidic acid biosensor that reveals mechanisms of lipid production. Weckerly CC, Rahn TA, Ehrlich M, Wills RC, Pemberton JG, Airola MV, Hammond GRV. J Cell Biol. 2025 Nov 3;224(11):e202405174. doi: 10.1083/jcb.202405174. Epub 2025 Sep 9. 10.1083/jcb.202405174 PubMed 40923975
