pBS-HYGRO-P2A-mAID-mCLOVER-LRR1
(Plasmid
#221546)
-
PurposeDONOR homology arm-containing repair template used to insert Auxin-Inducible Degron tags, mClover, and Hygromycin resistance markers to the N-terminus of LRR1
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 221546 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $89 |
Backbone
-
Vector backbonepBluescript KS II+
- Backbone size w/o insert (bp) 3000
- Total vector size (bp) 6000
-
Modifications to backboneHomology arm was inserted as detailed
-
Vector typeUnspecified
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameLRR1
-
SpeciesH. sapiens (human)
-
Insert Size (bp)3000
-
Entrez GeneLRR1 (a.k.a. 4-1BBLRR, LRR-1, PPIL5)
- Promoter N/A
-
Tag
/ Fusion Protein
- HYGRO-P2A-mAID-mCLOVER (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site SACI (unknown if destroyed)
- 3′ cloning site KNPI (unknown if destroyed)
- 5′ sequencing primer TCAACgagctcAGTTCTAAGTGCCTTTCCCTGTAAC
- 3′ sequencing primer ACTCAggtaccCAGTTATTTTACTGTTCCCCAACTG (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pBS-HYGRO-P2A-mAID-mCLOVER-LRR1 was a gift from Aga Gambus (Addgene plasmid # 221546 ; http://n2t.net/addgene:221546 ; RRID:Addgene_221546) -
For your References section:
Characterizing replisome disassembly in human cells. Jones RM, Ruiz JH, Scaramuzza S, Nath S, Liu C, Henklewska M, Natsume T, Bristow RG, Romero F, Kanemaki MT, Gambus A. iScience. 2024 Jun 12;27(7):110260. doi: 10.1016/j.isci.2024.110260. eCollection 2024 Jul 19. 10.1016/j.isci.2024.110260 PubMed 39055910
