pCDF_AaRaf1/Raf2/RbcX2/RbcX1
(Plasmid #229514)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 229514 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCDFDuet-1
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 3781
  • Total vector size (bp) 6625
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Streptomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    Rubisco accumulation factor 1
  • Alt name
    Raf1
  • Species
    Anthoceros agrestis
  • Insert Size (bp)
    1176
  • Mutation
    N terminus chloroplast transit peptide truncation
  • Promoter T7

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    Rubisco accumulation factor 2
  • Alt name
    Raf2
  • Species
    Anthoceros agrestis
  • Insert Size (bp)
    513
  • Mutation
    N terminus chloroplast transit peptide truncation
  • Promoter T7

Cloning Information for Gene/Insert 2

Gene/Insert 3

  • Gene/Insert name
    RbcX2
  • Species
    Anthoceros agrestis
  • Insert Size (bp)
    447
  • Mutation
    N terminus chloroplast transit peptide truncation
  • Promoter T7

Cloning Information for Gene/Insert 3

Gene/Insert 4

  • Gene/Insert name
    RbcX1
  • Species
    Anthoceros agrestis
  • Insert Size (bp)
    378
  • Mutation
    N terminus chloroplast transit peptide truncation
  • GenBank ID
  • Promoter T7

Cloning Information for Gene/Insert 4

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Removal of Anthoceros agrestis BSD2from pCDF_AaRaf1/Raf2/RbcX2/BSD2/RbcX1 was performed by Genscript.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCDF_AaRaf1/Raf2/RbcX2/RbcX1 was a gift from Laura Gunn (Addgene plasmid # 229514 ; http://n2t.net/addgene:229514 ; RRID:Addgene_229514)

  • For your References section:

    Unique biogenesis and kinetics of hornwort Rubiscos revealed by synthetic biology systems. Oh ZG, Robison TA, Loh DH, Ang WSL, Ng JZY, Li FW, Gunn LH. Mol Plant. 2024 Dec 2;17(12):1833-1849. doi: 10.1016/j.molp.2024.10.013. Epub 2024 Nov 2. 10.1016/j.molp.2024.10.013 PubMed 39491367
