AiP12068 - pAAV-DLX2.0-minBG-ChrimsonR-tdTomato-WPRE3-BGHpA (Alias: CN2068)
(Plasmid #229775)

• Purpose: enhancer AAV for expression of ChrimsonR-tdTomato under the DLX2.0 enhancer
• Depositing Labs: The Allen Institute for Brain Science, Jonathan Ting
• Publication: Matveev et al bioRxiv 2024.11.01.621418

Want a viral vector made from this plasmid?

Make a packaging request and we'll get back to you.

This service is available to academics and nonprofits only.

Please log in to submit a packaging request.

• Serotype: Select serotype for details See details about
• Pricing: Select serotype and quantity $ USD for preparation of µL virus + $30 USD for plasmid.
• How this works:
  • Place a request for a quantity of 10 (1 mL), 25 (2.5 mL), or 50 (5 mL). Our all-inclusive pricing includes DNA production and QC.
  • Addgene will quickly confirm that we can produce a high-quality prep for you.
  • Track your request and place an order from within your account. Payment information must be added before we can begin processing your order.
  • Receive your prep in 6–9 weeks after the MTA is approved by your organization.
  • Learn more about our Packaged on Request Service.

Backbone

• Vector backbone: pAAV
• Vector type: Mammalian Expression, AAV

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 30°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: ChrimsonR-tdTomato
• Species: Synthetic
• Insert Size (bp): 2502
• Tag / Fusion Protein:
  • tdTomato (C terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: BamHI (not destroyed)
• 3′ cloning site: EcoRI (not destroyed)
• 5′ sequencing primer: n/a

Resource Information

• Supplemental Documents:
  • AiP12068.gb
• A portion of this plasmid was derived from a plasmid made by: Edward Boyden (Addgene plasmid # 59171); the ChrimsonR-tdTomato was subcloned from it.

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Please visit https://doi.org/10.1101/2024.11.01.621418 for bioRxiv preprint.
