8061-E36
(Plasmid
#234273)
-
PurposeGateway ORF Entry clone of mouse Smad6 with stop codon (for native or N-terminal fusions)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 234273 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepDonr-253
- Backbone size w/o insert (bp) 3155
-
Vector typeGateway Entry Clone
Growth in Bacteria
-
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameSmad6
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)1566
-
Entrez GeneSmad6 (a.k.a. Madh6, b2b390Clo)
Cloning Information
- Cloning method Gateway Cloning
- 5′ sequencing primer M13F 23-mer (5'-CCCAGTCACGACGTTGTAAAACG)
- 3′ sequencing primer attLR 23-mer (5'-TAACATCAGAGATTTTGAGACAC) (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
This gene contains 1 amino acid mutation from the RefSeq sequence. However, the C57Bl mouse genomic sequence matches the sequence here, suggesting the mutation is likely a SNP
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
8061-E36 was a gift from Dominic Esposito (Addgene plasmid # 234273 ; http://n2t.net/addgene:234273 ; RRID:Addgene_234273)
