pHK001.4
(Plasmid #235452)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 235452 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pColA
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NOT gate
  • Alt name
    sfGFP
  • Alt name
    mCherry
  • Species
    Escherichia coli

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

JM101 (working strain for phagemid transfer). Requires the dCas9 plasmid, pJ1996v2 (Addgene plasmid #140664). Please visit https://doi.org/10.1101/2024.08.28.610043 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHK001.4 was a gift from Yolanda Schaerli (Addgene plasmid # 235452 ; http://n2t.net/addgene:235452 ; RRID:Addgene_235452)

  • For your References section:

    Engineering intercellular communication using M13 phagemid and CRISPR-based gene regulation for multicellular computing in Escherichia coli. Kusumawardhani, H., Zoppi, F., Avendaño, R. et al.. Nat Commun 16, 3569 (2025) 10.1038/s41467-025-58760-z
