pCAD130_hIrg1_M154I_pvp008
(Plasmid #239117)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 239117 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCOLADuet-1
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 3519
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    cis-aconitate decarboxylase
  • Species
    H. sapiens (human)
  • Mutation
    M154I
  • GenBank ID
    NM_001258406
  • Entrez Gene
    ACOD1 (a.k.a. CAD, IRG1)
  • Promoter T7
  • Tag / Fusion Protein
    • StrepTag-II (N terminal on backbone)

Cloning Information

  • Cloning method Golden Gate
  • 5′ sequencing primer TACGACTCACTATAGGGGAATTGTG
  • 3′ sequencing primer TGCTAGTTATTGCTCAGCGGTGGC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCAD130_hIrg1_M154I_pvp008 was a gift from Konrad Buessow (Addgene plasmid # 239117 ; http://n2t.net/addgene:239117 ; RRID:Addgene_239117)

  • For your References section:

    Amino acid positions near the active site determine the reduced activity of human ACOD1 compared to murine ACOD1. Chen F, Yalcin I, Zhao M, Chen C, Blankenfeldt W, Pessler F, Bussow K. Sci Rep. 2023 Jun 26;13(1):10360. doi: 10.1038/s41598-023-37373-w. 10.1038/s41598-023-37373-w PubMed 37365251
