pBK1576
(Plasmid #239796)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 239796 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    Lentiviral vector
  • Backbone manufacturer
    Duke VVC
  • Total vector size (bp) 11794
  • Vector type
    Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pLV-U6-[empty]-EFSNC-dSaCas9-KRAB-MeCp2-P2A-Puro-WPRE
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    8240
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site MluI (not destroyed)
  • 3′ cloning site MluI (not destroyed)
  • 5′ sequencing primer CMV F
  • 3′ sequencing primer WPRE L
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBK1576 was a gift from Boris Kantor (Addgene plasmid # 239796 ; http://n2t.net/addgene:239796 ; RRID:Addgene_239796)

  • For your References section:

    Downregulation of SNCA Expression by Targeted Editing of DNA Methylation: A Potential Strategy for Precision Therapy in PD. Kantor B, Tagliafierro L, Gu J, Zamora ME, Ilich E, Grenier C, Huang ZY, Murphy S, Chiba-Falek O. Mol Ther. 2018 Nov 7;26(11):2638-2649. doi: 10.1016/j.ymthe.2018.08.019. Epub 2018 Aug 29. 10.1016/j.ymthe.2018.08.019 PubMed 30266652
