pAJC1
(Plasmid
#240164)
-
PurposeProduction of a thermostable enzyme, Pyrobaculum calidifontis manganese-dependent catalase, to be used in an educational laboratory exercise.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 240164 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $89 |
Backbone
-
Vector backbonepET41 a(=)
-
Backbone manufacturerNovagen
- Backbone size w/o insert (bp) 5933
- Total vector size (bp) 5925
-
Vector typeBacterial Expression
-
Selectable markersKanamycin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert 1
-
Gene/Insert namekatPc
-
Alt namePyrobaculum calidifontis manganese dependent catalase
-
Alt namemanganese catalase
-
Alt namePc-kat
-
SpeciesPyrobaculum calidifontis
-
Insert Size (bp)897
-
GenBank IDAB076020 ab076020
- Promoter T7
Cloning Information for Gene/Insert 1
- Cloning method Restriction Enzyme
- 5′ cloning site NdeI (not destroyed)
- 3′ cloning site HindIII (not destroyed)
- 5′ sequencing primer nanopore sequencing. no sequencing primer used. (Common Sequencing Primers)
Gene/Insert 2
-
Gene/Insert namePc- kat
-
Alt namePyrobaculum calidifontis manganese catalase
-
SpeciesPyrobaculum calidifontis
-
Insert Size (bp)897
-
GenBank ID
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAJC1 was a gift from Danielle Saunders (Addgene plasmid # 240164 ; http://n2t.net/addgene:240164 ; RRID:Addgene_240164)
