pMi[3xP3::mCherry-SV40, Plodia-FibL::mBaojin-P10]
(Plasmid #240410)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 240410 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pBluescript, pMi(3xP3-EGFP)
  • Backbone size w/o insert (bp) 4018
  • Total vector size (bp) 7403
  • Modifications to backbone
    The pMi[3xP3::mCherry-SV40, Plodia-FibL::mBaojin-P10] plasmid was produced using Gibson Assembly, by replacing the EGFP-SV40 section of pMi(3xP3::EGFP-SV40) with a synthetic (mCherry-SV40, FibL::mBaojin-P10) gene fragment
  • Vector type
    Insect Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    3xP3::mCherry_SV40terminator
  • Species
    Synthetic
  • Insert Size (bp)
    1217
  • Promoter 3xP3

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    FibL::mBaojin_P10terminator
  • Species
    Synthetic
  • Insert Size (bp)
    2402
  • Entrez Gene
    Fib-l
  • Promoter Fibroin-L proximal promoter (Plodia interpunctella)

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMi[3xP3::mCherry-SV40, Plodia-FibL::mBaojin-P10] was a gift from Arnaud Martin (Addgene plasmid # 240410 ; http://n2t.net/addgene:240410 ; RRID:Addgene_240410)
