pICSL30014
(Plasmid #245534)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 245534 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pUAP
  • Backbone size w/o insert (bp) 2049
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    N-Terminal tag mTagBFP2
  • Species
    Synthetic
  • Insert Size (bp)
    715
  • Mutation
    BsaI/BpiI sites removed by point-mutation

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsaI (destroyed during cloning)
  • 3′ cloning site BsaI (destroyed during cloning)
  • 5′ sequencing primer AAATAGGCGTATCACGAGG
  • 3′ sequencing primer CGCGAAGTAATCTTTTCGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Level 0 N-Terminal tag module used for GoldenGate assemblies using the MoClo overhang syntax

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pICSL30014 was a gift from Mark Youles (Addgene plasmid # 245534 ; http://n2t.net/addgene:245534 ; RRID:Addgene_245534)
