CMV-huCof R21Q-mRFP
(Plasmid #245964)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 245964 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pShuttle CMV
  • Backbone manufacturer
    Gift from Bert Vogelstein in 1999
  • Backbone size w/o insert (bp) 7470
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    cofilin 1 (cfl1)
  • Species
    H. sapiens (human)
  • Mutation
    R21Q
  • Entrez Gene
    CFL1 (a.k.a. CFL, HEL-S-15, cofilin)
  • Promoter CMV
  • Tag / Fusion Protein
    • mRFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Unspecified (unknown if destroyed)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

R21Q and K22Q mutations are both used as cofilin-actin rod reporters.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CMV-huCof R21Q-mRFP was a gift from James Bamburg (Addgene plasmid # 245964 ; http://n2t.net/addgene:245964 ; RRID:Addgene_245964)

  • For your References section:

    A genetically encoded reporter for real-time imaging of cofilin-actin rods in living neurons. Mi J, Shaw AE, Pak CW, Walsh KP, Minamide LS, Bernstein BW, Kuhn TB, Bamburg JR. PLoS One. 2013 Dec 31;8(12):e83609. doi: 10.1371/journal.pone.0083609. PubMed 24391794
