ER-GFP Q185N N186C pLVX CMVpuro
(Plasmid #246913)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 246913 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pLVX CMV-puro
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    30°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    EGFP
  • Species
    Synthetic
  • Mutation
    Q185N N186C STT3B-specific sequon to allow for fluorescent monitoring of STT3B activity
  • Promoter CMV
  • Tags / Fusion Proteins
    • ER signal sequence (N terminal on insert)
    • KDEL ER retention sequence (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV-F
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    ER-GFP Q185N N186C pLVX CMVpuro was a gift from William Kaelin (Addgene plasmid # 246913 ; http://n2t.net/addgene:246913 ; RRID:Addgene_246913)

  • For your References section:

    Positive selection CRISPR screens reveal a druggable pocket in an oligosaccharyltransferase required for inflammatory signaling to NF-kappaB. Lampson BL, Ramiotarez AS, Baro M, He L, Hegde M, Koduri V, Pfaff JL, Hanna RE, Kowal J, Shirole NH, He Y, Doench JG, Contessa JN, Locher KP, Kaelin WG Jr. Cell. 2024 Apr 25;187(9):2209-2223.e16. doi: 10.1016/j.cell.2024.03.022. 10.1016/j.cell.2024.03.022 PubMed 38670073
