pKLV2-U6gRNA5(sgCXCR2-2)-PGKpuro2ABFP-W
(Plasmid #252918)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 252918 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pKLV2-U6gRNA5(BbsI)-PGKpuro2ABFP-W
  • Backbone manufacturer
    Kosuke Yusa
  • Backbone size w/o insert (bp) 8648
  • Vector type
    CRISPR
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CXCR2
  • gRNA/shRNA sequence
    GAAGATGACCAGCATCACGA
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    20
  • Entrez Gene
    CXCR2 (a.k.a. CD182, CDw128b, CMKAR2, IL8R2, IL8RA, IL8RB, WHIMS2)
  • Promoter human U6 promoter, mouse PGK promoter

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BbsI (destroyed during cloning)
  • 3′ cloning site BbsI (destroyed during cloning)

Resource Information

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pKLV2-U6gRNA5(sgCXCR2-2)-PGKpuro2ABFP-W was a gift from Sok Ching Cheong (Addgene plasmid # 252918 ; http://n2t.net/addgene:252918 ; RRID:Addgene_252918)
