pFlagTurboNTD(C1)-NIPP1
(Plasmid #253068)

Print

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 253068 Standard format: Plasmid sent in bacteria as agar stab 1 $89 *
Add to Cart

* Log in to view industry pricing.

Backbone

  • Vector backbone
    pFlagTurboCTD(C1)
  • Backbone manufacturer
    Laura Trinkle-Mulcahy
  • Backbone size w/o insert (bp) 4598
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NIPP1
  • Alt name
    PPP1R8
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1053
  • Entrez Gene
    PPP1R8 (a.k.a. ARD-1, ARD1, NIPP-1, NIPP1, PRO2047)
  • Promoter CMV
  • Tag / Fusion Protein
    • FlagTurboNTD (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer GCTGGGAGCAGACAAG
  • 3′ sequencing primer TGTGGTATGGCTGATTATG
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pFlagTurboNTD(C1)-NIPP1 was a gift from Laura Trinkle-Mulcahy (Addgene plasmid # 253068 ; http://n2t.net/addgene:253068 ; RRID:Addgene_253068)
