pEF6_hNLRP3(WalkerAB)-mCherry (KS559)
(Plasmid #259231)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 259231 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart

Backbone

  • Vector backbone
    pEF6
  • Vector type
    Mammalian Expression, Bacterial Expression
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    NLRP3
  • Alt name
    NALP3
  • Species
    H. sapiens (human)
  • Entrez Gene
    NLRP3 (a.k.a. AGTAVPRL, AII, AVP, C1orf7, CIAS1, CLR1.1, DFNA34, FCAS, FCAS1, FCU, KEFH, MWS, NALP3, PYPAF1)
  • Promoter EF-1a, T7
  • Tag / Fusion Protein
    • mCherry (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer T7 (TAATACGACTCACTATAGG)
  • 3′ sequencing primer BGH (TAGAAGGCACAGTCGAGG)
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEF6_hNLRP3(WalkerAB)-mCherry (KS559) was a gift from Kate Schroder (Addgene plasmid # 259231 ; http://n2t.net/addgene:259231 ; RRID:Addgene_259231)

  • For your References section:

    NLRP12 interacts with NLRP3 to block the activation of the human NLRP3 inflammasome. Coombs JR, Zamoshnikova A, Holley CL, Maddugoda MP, Teo DET, Chauvin C, Poulin LF, Vitak N, Ross CM, Mellacheruvu M, Coll RC, Heinz LX, Burgener SS, Emming S, Chamaillard M, Boucher D, Schroder K. Sci Signal. 2024 Jan 23;17(820):eabg8145. doi: 10.1126/scisignal.abg8145. Epub 2024 Jan 23. 10.1126/scisignal.abg8145 PubMed 38261657
