pDRAV-2
(Plasmid #26747)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 26747 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBluescript II KS
  • Backbone manufacturer
    Stratagene
  • Backbone size (bp) 3000
  • Vector type
    Mammalian Expression, Cre/Lox ; FLP/FRT; PhiC31/attB-attP
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    None

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ cloning site SacI (not destroyed)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer T7, M13Fw
  • 3′ sequencing primer T3, M13Rv
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry

Depositor Comments

The pDRAV plasmid series encode a 5' loxP site and a 3' FRT site in all possible orientations for dual RMCE (dRMCE) as described in Osterwalder et al. "Dual RMCE for efficient re-engineering of mouse mutant alleles" Nature Methods (2010) DOI 10.1038/nmeth.1521

Protocol for using these plasmids can be found here: http://www.nature.com/protocolexchange/protocols/1906

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDRAV-2 was a gift from Rolf Zeller (Addgene plasmid # 26747 ; http://n2t.net/addgene:26747 ; RRID:Addgene_26747)
  • For your References section:

    Dual RMCE for efficient re-engineering of mouse mutant alleles. Osterwalder M, Galli A, Rosen B, Skarnes WC, Zeller R, Lopez-Rios J.. Nat Methods. 2010 Oct 17 10.1038/nmeth.1521 PubMed 20953177
