|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||27691||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 4722
Vector typeMammalian Expression
Selectable markersNeomycin (select with G418)
Growth in Bacteria
Bacterial Resistance(s)Kanamycin, 50 μg/mL
SpeciesM. musculus (mouse)
Insert Size (bp)2000
Entrez GenePicalm (a.k.a. CALM, CLTH, PAP180, fit-1, fit1, mKIAA4114)
/ Fusion Protein
- mCherry (C terminal on insert)
- Cloning method Restriction Enzyme
- 5′ cloning site XhoI (not destroyed)
- 3′ cloning site XmaI (not destroyed)
- 5′ sequencing primer CMV-F
- 3′ sequencing primer mCherry-R 5'-TTGGTCACCTTCAGCTTGG (Common Sequencing Primers)
Articles Citing this Plasmid
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
Cloned from IMAGE clone: 2651109 (MGC:19382).
This plasmid may be slow growing in bacteria. For difficult constructs you can use TG1s (they are Endonuclease positive, but good for cloning) and INV F' E.coli strains. The latter give the best results. Also when growing in culture try to switch to 2xTY media, which is richer that LB.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:CALM-pmCherryN1 was a gift from Christien Merrifield (Addgene plasmid # 27691 ; http://n2t.net/addgene:27691 ; RRID:Addgene_27691)
For your References section:A high precision survey of the molecular dynamics of Mammalian clathrin-mediated endocytosis. Taylor MJ, Perrais D, Merrifield CJ. PLoS Biol. 2011 Mar . 9(3):e1000604. 10.1371/journal.pbio.1000604 PubMed 21445324
