(Plasmid #28304)


Item Catalog # Description Quantity Price (USD)
Plasmid 28304 Standard format: Plasmid sent in bacteria as agar stab 1 $75
AAV PHP.eB 28304-PHPeB Viral service discontinued.

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Scott Sternson
  • Backbone size w/o insert (bp) 5047
  • Vector type
    Mammalian Expression, AAV, Cre/Lox ; Adeno-associated virus

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    Use recombinase-free E. coli (Stbl3, XL-10, Sure2, grow at 30C
  • Copy number
    Low Copy


  • Gene/Insert name
  • Alt name
    Green fluorescent protein
  • Species
    A. victoria
  • Insert Size (bp)
  • Mutation
  • Promoter CAG

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site BsrGI (not destroyed)
  • 5′ sequencing primer cttctggcgtgtgaccgg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments


Information for AAV PHP.eB (Catalog # 28304-PHPeB) ( Back to top )


Ready-to-use AAV PHP.eB particles produced from pAAV-FLEX-GFP (#28304). In addition to the viral particles, you will also receive purified pAAV-FLEX-GFP plasmid DNA.

CAG-driven, Cre-dependent GFP expression control. These AAV were produced with the PHPeB serotype, which permits efficient transduction of the central nervous system. These AAV preparations are suitable purity for injection into animals.


  • Volume .
  • Titer ≥ 1×10¹³ vg/mL
  • Pricing $350 USD for preparation of . virus + $30 USD for plasmid.
  • Storage Store at -80℃. Thaw just before use and keep on ice.
  • Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.

Viral Production & Use

  • Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, PHP.eB cap gene
    pUCmini-iCAP-PHP.eB (plasmid #103005)
  • Buffer PBS + 0.001% Pluronic F-68
  • Serotype PHPeB (plasmid #103005)
  • Purification Iodixanol gradient ultracentrifugation
  • Reporter Gene GFP (Cre-dependent)


Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide

Terms and Licenses

Viral Quality Control

Quality Control:
  • Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
  • Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.

Please note that this vector has a higher level of recombination than our other FLEX vectors (higher than 0.8% recombination referenced below). We are making it available because it is still useful to some scientists, but understand that you may see higher levels of off-target expression in the absence of Cre.

Visit our viral production page for more information.

Addgene Comments

Using FLEX vectors in vivo: LoxP sites in FLEX plasmids are known to recombine during DNA amplification and viral vector production, which may result in a minority of Cre-activated (i.e., "flipped") viral vectors. Addgene has measured this occurs in 0.1-0.8% of viral particles in our typical production protocol. This can lead to a small number of cells exhibiting Cre-independent transgene expression in vivo. To address this, it is necessary to optimize the injection volume and viral titer to find the optimal AAV dosage required for Cre-dependent transgene expression and function in vivo. This may include reducing the viral particle dosage in order to reduce the likelihood of Cre-independent expression.

Citation Information: When using the PHP.eB serotype in future publications, please acknowledge Viviana Gradinaru and cite Chan et al., Nat Neurosci, 20(8):1172-1179. Pubmed.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-FLEX-GFP was a gift from Edward Boyden (Addgene plasmid # 28304 ; ; RRID:Addgene_28304)

    For viral preps, please replace (Addgene plasmid # 28304) in the above sentence with: (Addgene viral prep # 28304-PHPeB)
