Reduced Expression GFP beta actin
(Plasmid #31502)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 31502 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4250
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    beta actin
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1100
  • Mutation
    91-544 of enhancer region of CMV promoter deleted
  • GenBank ID
    NM_001101
  • Entrez Gene
    ACTB (a.k.a. BKRNS, BNS, BRWS1, CSMH, DDS1, PS1TP5BP1, THC8)
  • Tag / Fusion Protein
    • EGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer EGFP-C
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Reduced Expression GFP beta actin was a gift from Rick Horwitz & Tim Mitchison (Addgene plasmid # 31502 ; http://n2t.net/addgene:31502 ; RRID:Addgene_31502)
  • For your References section:

    Single-molecule speckle analysis of actin filament turnover in lamellipodia. Watanabe N, Mitchison TJ. Science. 2002 Feb 8. 295(5557):1083-6. 10.1126/science.1067470 PubMed 11834838
