PurposeDoxycyline regulated expression of Tbx5 in mammalian cells
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||72688||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 11391
Vector typeMammalian Expression, Lentiviral
Growth in Bacteria
Growth Strain(s)NEB Stable
Copy numberHigh Copy
Gene/Insert nameTbx 5
SpeciesM. musculus (mouse)
- Promoter CMV-Doxycycline
- Cloning method Gateway Cloning
- 5′ sequencing primer pSAM 2 SEQ F - 5' GCTCGTTTAGTGAACCGTCAG 3'
- 3′ sequencing primer pSAM2 SEQ R - 5' GAGGAACTGCTTCCTTCACG 3' (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pSAM2_mCherry_Tbx5 was a gift from Timothy Kamp (Addgene plasmid # 72688 ; http://n2t.net/addgene:72688 ; RRID:Addgene_72688)
For your References section:Lineage Reprogramming of Fibroblasts into Proliferative Induced Cardiac Progenitor Cells by Defined Factors. Lalit PA, Salick MR, Nelson DO, Squirrell JM, Shafer CM, Patel NG, Saeed I, Schmuck EG, Markandeya YS, Wong R, Lea MR, Eliceiri KW, Hacker TA, Crone WC, Kyba M, Garry DJ, Stewart R, Thomson JA, Downs KM, Lyons GE, Kamp TJ. Cell Stem Cell. 2016 Mar 3;18(3):354-67. doi: 10.1016/j.stem.2015.12.001. Epub 2016 Feb 11. 10.1016/j.stem.2015.12.001 PubMed 26877223
