SQT1659
(Plasmid #78743)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 78743 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pCAG-GFP
  • Backbone manufacturer
    Cepko lab (Addgene plasmid# 11179)
  • Vector type
    Mammalian Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mammalian codon-optimized Acidaminococcus sp. BV3L6 Cpf1-NLS-3xHA
  • Alt name
    Cpf1
  • Species
    Acidaminococcus sp. BV3L6
  • Promoter CAG
  • Tags / Fusion Proteins
    • NLS (C terminal on insert)
    • 3x HA (C terminal on insert)

Cloning Information

  • Cloning method Unknown
  • 5′ sequencing primer pCAG-F (5'-GCAACGTGCTGGTTATTGTG-3')
  • 3′ sequencing primer M13-rev
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

This plasmid expresses Cpf1 from Acidaminococcus sp. BV3L6 in mammalian cells. Recommended to use with BPK3079 (Addgene plasmid# 78741), which can be used to express a gRNA for AsCpf1.

Please visit https://www.biorxiv.org/content/early/2016/06/09/057802 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    SQT1659 was a gift from Keith Joung (Addgene plasmid # 78743 ; http://n2t.net/addgene:78743 ; RRID:Addgene_78743)
  • For your References section:

    Genome-wide specificities of CRISPR-Cas Cpf1 nucleases in human cells. Kleinstiver BP, Tsai SQ, Prew MS, Nguyen NT, Welch MM, Lopez JM, McCaw ZR, Aryee MJ, Joung JK. Nat Biotechnol. 2016 Jun 27. doi: 10.1038/nbt.3620. 10.1038/nbt.3620 PubMed 27347757
