PurposeSoybean APEX2 anchored to cytosolic face of outer mitochondrial membrane with C-terminal targeting sequence of last 31aa of human mitochondrial antiviral-signaling protein
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||79056||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 7737
- Total vector size (bp) 8616
Vector typeMammalian Expression, Bacterial Expression, Lentiviral
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Growth Strain(s)NEB Stable
Gene/Insert nameSoybean APEX2
Insert Size (bp)876
- Promoter CMV immearly promotor
/ Fusion Proteins
- last 31 amino acids of human MAVS (C terminal on insert)
- flag (N terminal on insert)
- Cloning method Unknown
- 5′ sequencing primer CMV-forward (Common Sequencing Primers)
Article Citing this Plasmid
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
Additional publication for this plasmid:
Proteomic mapping of cytosol-facing outer mitochondrial and ER membranes in living human cells by proximity biotinylation.
Hung et. al. Elife 2017 https://www.ncbi.nlm.nih.gov/pubmed/28441135
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:APEX2-OMM was a gift from Alice Ting (Addgene plasmid # 79056 ; http://n2t.net/addgene:79056 ; RRID:Addgene_79056)
For your References section:Directed evolution of APEX2 for electron microscopy and proximity labeling. Lam SS, Martell JD, Kamer KJ, Deerinck TJ, Ellisman MH, Mootha VK, Ting AY. Nat Methods. 2014 Nov 24. doi: 10.1038/nmeth.3179. 10.1038/nmeth.3179 PubMed 25419960
